Merging Technologies Merging NADAC + Power

Available for purchase is the Merging Technologies +NADAC DAC with +POWER power supply two channel DAC, a two box solution made in Switzerland of the highest quality.

This is one of the finest DACs on the market providing remarkable flexibility to input AES-EBU, SPDIF, Optical or Ethernet (Ravenna) and also provides for clocking capability via its BNC connection.  The remarkable simplicity yet flexibility of this two box solution is detailed on their web page at:  MERGING+NADAC | PRODUCT.

It has received the top accolades from the high end audio press and comes from a company with decades of both professional audio and high end audio experience.  Merging Technologies is part of Neumann and the Sennheiser Group, so you can be assured of long standing and extensive support.


Outputs

Balanced Analog Output

•  Connector: gold-plated male XLR
•  Impedance: 40 Ohms
•  Max output level: 18 dBu (6.1 Vrms)
•  Multichannel dynamic range: 124 dB(A)
•  Multichannel THD+N @1kHz: -113 dB (0.00022 %)
•  Stereo dynamic range: 130 dB(A)
•  Stereo THD+N @1kHz: -116 dB (0.00016 %)

Unbalanced Analog Output

•  Connector: gold-plated RCA jacks
•  Impedance: 20 Ohms
•  Max output level: 8.2 dBu (2 Vrms)
•  Multichannel dynamic range: 120 dB(A)
•  Multichannel THD+N @1kHz: -113 dB (0.00022 %)
•  Stereo dynamic range: 123 dB(A)
•  Stereo THD+N @1kHz: -114 dB (0.0002 %)

Headphone

•  Connector: 3.5mm jack + 6mm jack
•  Impedance: 40 Ohms
•  Max output level: 14.4 dBu (4.0 Vrms)
•  Dynamic range: 123 dB(A)
•  THD+N @1kHz: -111 dB (0.00028 %)

Inputs

AES input

•  Connector: gold-plated female XLR
•  Input impedance: 110 Ohms
•  Sample rate: 44.1 kHz – 192 kHz

S/PDIF optical input

•  Connector: Toslink
•  Sample rate: 44.1 kHz – 96 kHz

S/PDIF coaxial input

•  Connector: gold-plated RCA jack
•  Input impedance: 75 Ohms
•  Sample rate: 44.1 kHz – 96 kHz

Network input

•  Connector: Neutrik EtherCon RJ45
•  Bitrate: 1 Gb/s (Gigabit Ethernet only)
•  Sample rate: 44.1 kHz – 384 kHz, DSD64, DSD128 and DSD256

WordClock input

•  Connector: BNC
•  Input impedance: 75 Ohms
•  Termination: 75 Ohms, software selectable
•  Sample rate: 44.1 kHz – 192 kHz

Misc

•  Enclosure material: Premium machined and anodized aluminium
•  Dimension: 435 W x 435 D x 95 H mm
•  Weight: 11 kg
•  AC voltage: 100V-240V/47-63Hz (IEC socket)
•  Power consumption: < 30W
•  Front panel display: OLED, 160x128 pixels, 16 bit colors

Priced to move, this is a remarkable addition to any high end system.

PHOTOS TO BE UPLOADED SHORTLY.
