Emotiva XPA11 GEN3

Selling my Emotiva XPA-11 Gen3 11 channel amplifier. This amp has 3 high-powered class A/B single channels for your left, right, and center channels and then 8 class H channels for your other channels. I love the amp and it has served me well, but I moved to a new location and don't have the space for the same setup that I used to. Comes with original packaging and owners manual. Specifications below.

Audio Specifications

• The XPA-11 Gen3 features three of our High-Powered Single Channel Modules and four of our Stereo Modules.

Audio Specifications (High-Powered Single Channel Modules):

Power Output:

• 300 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven

• 550 watts RMS/channel; 20 Hz – 20 kHz; THD<0.2%; 4 Ohms; one channel driven

• 300 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven

• 490 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven

Power Bandwidth (at rated power; 4 Ohm - 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB)

Broad Band Frequency Response: 5 Hz to 80 kHz +0/-2 dB

THD + noise: < 0.005%; at 100 watts RMS; 1 kHz; 8 Ohms.

Signal to Noise Ratio (8 Ohm load):

• > 115 dB; ref FTC rated power; unbalanced input (A-weighted)

• > 86 dB; ref 1 watt; unbalanced input (A-weighted)

Minimum Recommended Load Impedance (per channel): 4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads)

Damping Factor (8 Ohm load): > 500

Input Sensitivity (for rated power; 8 Ohm load): 1.71 V

Gain: 29 dB

Maximum Power Consumption: 2,600 watts


Audio Specifications (Stereo Modules):

Power Output:

• 65 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven

• 100 watts RMS/channel; 20 Hz – 20 kHz; THD<0.2%; 4 Ohms; one channel driven

• 65 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven

• 100 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven

Power Bandwidth (at rated power; 4 Ohm - 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB)

Broad Band Frequency Response: 50 Hz to 80 kHz +0/-1.5 dB

THD + noise: < 0.02%; at 60 watts RMS; 1 kHz; 8 Ohms

Signal to Noise Ratio (8 Ohm load):

• > 105 dB; ref FTC rated power; unbalanced input (A-weighted)

• > 85 dB; ref 1 watt; unbalanced input (A-weighted)

Minimum Recommended Load Impedance (per channel): 4 Ohms (one 4 Ohm load or two paralleled 8 Ohm loads)

Damping Factor (8 Ohm load): > 500

Input Sensitivity (for rated power; 8 Ohm load): 0.8 V (800 mV)

Gain: 29 dB
